Car Remote Vehicle Mounted Jammer , Gps Tracking Device For Bomb Jamming

Car Remote Vehicle Mounted Jammer Gps Tracking Device For Bomb Jamming

Product Description

TSL-VM is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.

1. Designed with ultra broadband frequency bands, 20MHz-3600MHz (20-6000MHz).
2. 12 modules plug and play design, facilitate for future power upgrading, change and maintenance. Any ruin on the modules never interfere the normal operating of other modules.
3. American Mil-spec standard case, shockproof and drop-resistance, available for the vehicle running in a worse field environment.
4. Up to 20 Frequency Bands. All Jamming Modules Designed by DDS technology.
5. Operators are able to regulate the working frequency band and output power of each module through the software. Configuring a specific frequency band can ensure the internal communication in emergency.
6. System operation can be performed in the driver's console unit. Each module can be ON/OFF. Backup battery or generator system can be optional.
7. Continuously and simultaneously interference to the common used RF signals.
8. Equipped with high power generator to ensure excellent low noise operational capabilities.
9. Integrated backup battery system for continuous silent operation and fast start.
10. Integrated smart active cooling system to make sure the device working continuously.
11. Antenna is installed with a covert design.
12. Video camera with LCD monitor both inside and outside the vehicle provide rear viewing and monitoring

Protecting military and VIP convoys from the threat of Remote Control Improvised Explosive Devices (RCIEDs)-road-side bombs has become a challenge and task in many parts of the world.

The Jammer is a vehicle mounted very high power jammer designed for blocking remote controlled improvised explosive devices(RCIED) Used by terrorist.
The Jammer is using state-of-art technology for maximum performance and jamming the signals transmits to activate bombs.

Jamming radius of the Jammer depends on several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.

Features
1. Using DDS Jamming technology to make the Frequency setting more precise
2. High efficient output power, long jamming radius
3. Slow start up design of circuit to make the device work stably.
4. Perfect Self Protection, Over Heat protection, Over current protection, High input Voltage and low Voltage protection, VSWR protection
5. Easy operation, using Wire Control Panel to monitor the system
6. Integrated backup battery can support the Jammer to work one hour

Applications
1. Military Convoy
2. VIP Protection
3. RIOT Control
4. S.W.A.T Team
5. EOD Operations
6. Electronic countermeasure, etc

Power Amplifier Protection
A. Over Heat protection Thermal protector
B. Over current protection
C. High input Voltage and low Voltage protection
D. VSWR protection: against antenna miss-match including open and short circuit

Remote Control

Wire Control Panel available
A. Output power LCD Indication
B. Output power adjusting by LCD
C. Output power on/off per band
D. Jamming frequency setting by LCD Panel

Specifications:

Customized Isolating Signal Bandwidth

Wecome to do OEM/ODM, we can do customized frequency based above frequencies.
